Запчасти Komatsu PC38UU-3 MULTI PATERN (ДЛЯ WAY) (КЛАПАН)(№7-8) ГИДРАВЛИКА

|1

22M-62-14201

VALVE ASS'Y

1

22F-62-13271

PLATE

2

01252-40618

BOLT

3

01643-30623

WASHER

4

22F-62-13261

PLATE

5

22M-62-13240

PLATE

6

20T-62-76440

COVER

7

01252-40620

BOLT

8

07016-00306

SEAL

9

203-62-58950

BODY

10

07000-03028

O-RING

11

07000-02060

O-RING

12

22F-62-13250

PLUG

13

04260-00793

BALL

14

700-84-11750

SPRING

15

20T-62-76430

SHAFT

16

203-62-58980

COVER

17

01252-40616

BOLT

18

201-62-75420

ELBOW

19

07235-10210

ELBOW

19A

21U-62-24160

ELBOW

20

07002-11423

O-RING

21

20C-62-34690

HOSE¤ 120MM,RED

22

20C-62-34690

HOSE¤ 120MM,ORANGE

23

20C-62-34690

HOSE¤ 120MM,BROWN

24

20C-62-34690

HOSE¤ 120MM,WHITE

25

21U-62-38320

HOSE¤ 300MM,BLUE

26

21X-62-32330

HOSE¤ 200MM,YELLOW

27

20C-62-34720

HOSE¤ 150MM,BLACK

28

21X-62-32340

HOSE¤ 300MM,BROWN

29

20C-62-34750

HOSE¤ 150MM,GREEN

30

08210-01215

SPIRAL TUBE
