Запчасти Komatsu PC38UU-3 ОСНОВН. КЛАПАН (-КЛАПАН) (9/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
723-1A-12402
CONTROL VALVE
|1
723-1A-12401
CONTROL VALVE
1
723-11-18330
VALVE
2
723-11-18340
SPRING
3
708-7R-11220
PLUG
4
07002-11223
O-RING
5
723-11-18170
VALVE
6
723-11-18180
SPRING
7
723-11-18190
PLUG
8
07002-11023
O-RING
9
723-11-19880
PLUG
10
07000-11009
O-RING
11
07001-01009
RING,BACK-UP
12
723-11-18520
SEAT
13
723-11-19960
O-RING
14
723-11-18530
VALVE
15
723-11-18550
RETAINER
16
723-11-18540
SPRING
17
723-11-18120
PLUG
18
07001-01007
RING,BACK-UP
|19
723-11-00430
VALVE SUB ASS'Y
19
BLOCK
20
SPOOL
21
SPRING
22
PLUG
23
O-RING
24
723-11-19470
PLUG
25
723-11-19480
O-RING
26
723-11-19440
RETAINER
27
723-11-18540
SPRING
28
723-11-19450
VALVE
29
723-11-19460
SEAT
30
723-11-19960
O-RING
31
07000-11004
O-RING
32
07000-11009
O-RING
33
702-16-54490
SCREW
34
723-11-19490
O-RING
35
722-12-18240
O-RING
36
01252-60645
BOLT
37
723-11-19610
BLOCK
38
07000-12015
O-RING
39
07000-11007
O-RING
40
07000-11009
O-RING
41
07001-01009
RING,BACK-UP
42
723-11-19620
PLUG
43
709-32-11840
O-RING
44
07002-12034
O-RING
Выбрано товаров: 47
