Запчасти Komatsu PC38UU-3 МЕХАНИЗМ ПОВОРОТА (С РЕВЕРС PREВЕНТИЛЯТОРION КЛАПАН) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21X-26-00050

SWING MACHINERY A.

1

20S-26-81180

CARRIER

2

20S-26-81121

GEAR

3

20S-26-81260

PIN

4

20T-26-81430

BEARING

5

20S-26-71160

WASHER

6

20S-26-71190

RING

7

20S-26-71250

PIN

8

20S-26-81190

CARRIER

9

20S-26-81140

GEAR

10

20S-26-81250

PIN

11

201-26-62270

BEARING

12

20S-26-81151

GEAR

13

20S-26-81231

SPACER

14

20S-26-81160

SHAFT

15

20S-26-81280

BEARING

16

20S-26-81290

BEARING

17

20S-26-81210

SEAL

18

20S-26-81171

CASE

19

21T-09-11580

BOLT

20

01252-31080

BOLT

21

01643-51032

WASHER

22

20S-26-81240

WASHER

23

20S-26-81220

SEAL

24

20S-26-81110

GEAR

25

20S-26-81130

GEAR

26

07049-01215

PLUG

27

04064-04218

RING

28

04020-01434

PIN

29

708-7R-00330

MOTOR ASS'Y,(SEE FIG.Y1640-01A0)

30

20S-26-81310

RING

31

07000-12135

O-RING

32

07235-10315

ELBOW

33

07002-12034

O-RING

34

07230-20315

UNION

35

07002-12034

O-RING

36

07236-10210

ELBOW

37

07002-11423

O-RING

38

20T-62-71611

TEE

39

07002-11423

O-RING
