Запчасти Komatsu PC38UU-3 РУКОЯТЬ (РУКОЯТЬ) (ДЛЯ ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21X-957-3400

ARM,INNER

1

ARM,INNER

2

21X-70-31460

BUSHING

3

07145-00045

SEAL

4

07020-00675

FITTING,GREASE

5

20S-957-1182

PLATE

6

20S-957-1252

PLATE

7

20S-957-1291

PLATE

8

20S-957-1212

SHIM

9

20S-957-1222

SHIM

10

20S-957-1262

SHIM

11

20S-957-1272

SHIM

12

01010-80818

BOLT

13

01643-30823

WASHER

|14

21X-957-3500

ARM ASS'Y(OUTER)

14

ARM

15

20S-70-11270

BUSHING

16

20S-70-71880

BUSHING

17

07145-00035

SEAL

18

07020-00000

FITTING,GREASE

19

07020-00900

FITTING,GREASE

20

20S-957-1182

PLATE

21

20S-957-1192

PLATE

22

20S-957-1281

PLATE

23

21X-957-3380

PLATE

24

20S-957-1212

SHIM

25

20S-957-1222

SHIM

26

20S-957-1232

SHIM

27

20S-957-1242

SHIM

28

21X-957-3440

SHIM

29

21X-957-3450

SHIM

30

01010-80820

BOLT

31

01643-30823

WASHER

32

01010-80822

BOLT

33

01010-80816

BOLT

34

01643-30823

WASHER

35

01643-30823

WASHER

36

20S-957-1150

PIN

37

20S-957-1161

PIN

38

07020-00000

FITTING,GREASE

39

20S-957-1170

HOLDER

40

01010-80616

BOLT

41

01602-20619

WASHER
