Запчасти Komatsu PC38UU-3 ПЕРЕДН. COVER ЧАСТИ КОРПУСА

|1

21X-54-31500

COVER ASS'Y

1

21U-54-31612

COVER,FRONT

2

21U-54-31643

BRACKET

|2

22F-54-11270

BRACKET

3

01010-81020

BOLT

4

01643-31032

WASHER

5

22F-54-11280

HINGE

6

01010-81020

BOLT

7

01643-31032

WASHER

8

21U-54-31651

HINGE ASS'Y

9

01010-81020

BOLT

10

01643-31032

WASHER

11

22F-54-11390

PLATE

12

01643-30823

WASHER

13

04052-10833

PIN,SNAP

14

01010-81050

BOLT

15

01643-31032

WASHER

16

201-03-29160

SPACER

17

22F-54-11342

BRACKET

|17

22F-54-11341

BRACKET

|17

22F-54-11340

BRACKET

18

01010-81020

BOLT

19

01643-31032

WASHER

20

203-54-63230

CLAMP

|20

20C-54-11820

CLAMP

21

01023-10610

SCREW

|21

01220-40408

SCREW

22

01641-20405

WASHER

23

21X-54-31461

COVER

24

01010-81025

BOLT

25

01643-31032

WASHER

26

21X-54-31471

COVER

27

01010-D1030

BOLT

28

01643-71032

WASHER

29

21X-54-31482

COVER

30

01010-81025

BOLT

31

01643-31032

WASHER

32

21X-54-31540

SEAL

33

21X-54-31550

SEAL

34

21X-54-31560

SEAL
