Запчасти Komatsu PC38UU-2 ОСНОВН. НАСОС (/) (ДЛЯ ЯПОН.)(№-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

705-41-08080

PUMP ASS'Y

|1

705-41-04040

PUMP ASS'Y (SBR11)

1

705-40-80511

BRACKET

|1

705-40-80620

BUSHING,PLANE (DRIVE SIDE)

|1

705-40-80610

BUSHING,PLANE (DRIVEN SIDE)

2

705-40-23011

CASE,GEAR

3

705-41-80310

CARRIER

|3

705-40-80610

BUSHING,PLANE (DRIVE SIDE)

|3

705-40-80620

BUSHING,PLANE (DRIVEN SIDE)

4

705-40-23462

GEAR,DRIVE

5

705-40-23511

GEAR,DRIVEN

6

705-40-80720

PLATE,SIDE

7

705-40-80760

SEAL,RING

8

04020-00820

PIN,DOWEL

9

705-67-01230

PIN,DOWEL

10

705-17-02710

BOLT

11

01643-51232

WASHER

12

705-67-01330

COUPLING ASS'Y

13

705-40-80660

SEAL,RING

14

705-41-80750

BOLT

15

01643-50823

WASHER
