Запчасти Komatsu PC38UU-2 ОСНОВН. КЛАПАН (-КЛАПАН) (ДЛЯ КЛАПАН ЛЕВ.) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

709-36-13901

VALVE ASS'Y

|$3

709-36-13900

VALVE ASS'Y

|$7

709-36-00210

VALVE SUB ASS'Y

|$8

BODY SUB ASS'Y

1

BLOCK

2

BLOCK

3

BLOCK

4

07000-12055

O-RING

5

709-36-11530

STUD

6

01580-10806

NUT

7

SPOOL

8

SPOOL

9

709-32-11530

SEAL

10

709-32-11540

PLATE

11

709-32-11550

RETAINER

12

709-32-11560

COLLAR

13

709-32-11580

SPRING

14

01252-30620

BOLT

15

709-32-11570

COVER

16

01252-30610

BOLT

17

01252-30616

BOLT

18

709-32-12840

RETAINER

19

709-32-13510

SPRING

20

709-32-12851

CASE

21

709-32-11760

O-RING

22

01252-30622

BOLT

23

01641-20608

WASHER

24

709-32-12871

VALVE

25

722-10-91130

SPRING

26

709-32-12861

PLUG

27

709-32-11930

PLUG

28

07002-11823

O-RING

29

709-32-13551

SPRING

30

709-32-13531

POPPET

31

709-32-13541

JOINT

32

07000-11003

O-RING

33

07040-11007

PLUG

34

07002-11023

O-RING

35

700-28-55000

VALVE ASS'Y,RELIEF

36

709-30-63602

VALVE ASS'Y,SUCTION AND SAFETY

36

709-30-66700

SAFETY VALVE ASS'Y

37

709-30-63602

VALVE ASS'Y,SUCTION AND SAFETY
