Запчасти Komatsu PC38UU-2 МЕХАНИЗМ ПОВОРОТА И МОТОР (MACHINERY)(№8-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$1

21X-26-00022

SWING MACHINERY A.

|$2

21X-26-00021

SWING MACHINERY A.

|$3

21X-26-00020

SWING MACHINERY A.

1

20S-26-81180

CARRIER

2

20S-26-81121

GEAR

3

20S-26-81260

PIN

4

20T-26-81430

BEARING

5

20S-26-71160

WASHER

6

20S-26-71190

RING,SNAP

7

20S-26-71250

PIN

8

20S-26-81190

CARRIER

9

20S-26-81140

GEAR

10

20S-26-81250

PIN

11

201-26-62270

BEARING

12

20S-26-81151

GEAR

12

20S-26-81150

GEAR

13

20S-26-81231

SPACER

14

20S-26-81160

SHAFT

15

20S-26-81280

BEARING

16

20S-26-81290

BEARING

17

20S-26-81210

SEAL

18

20S-26-81171

CASE

18

20S-26-81170

CASE

19

21T-09-11580

BOLT

20

01252-31080

BOLT

21

01643-81032

WASHER

22

20S-26-81240

WASHER,THRUST

23

20S-26-81220

SEAL,OIL

24

20S-26-81110

GEAR

25

20S-26-81130

GEAR

26

07049-01215

PLUG

27

04064-04218

RING,SNAP

28

20U-26-22130

SHIM, 0.8MM

28

20U-26-22140

SHIM, 0.1MM

29

20U-26-22150

SHIM, 1.0MM
