Запчасти Komatsu PC38UU-1 ПОЛ КАБИНЫ (/) ЧАСТИ КОРПУСА

1

21X-54-11581

COVER

|1

21X-54-11850

COVER,(FOR VANDALISM PROTECTION)

|1

21X-54-11580

COVER

2

21X-54-11591

COVER

|2

21X-54-11590

COVER

3

203-54-32260

STOPPER

4

21X-54-11571

SHEET

|4

21X-54-11860

SHEET,(FOR VANDALISM PROTECTION)

|4

21X-54-11570

SHEET

5

20U-54-11581

COLLAR

|5

20U-54-11580

COLLAR

6

01010-51020

BOLT

7

01643-31032

WASHER

8

20U-54-11651

COLLAR

|8

20U-54-11650

COLLAR

9

01010-50616

BOLT

10

01643-30623

WASHER

11

01010-51020

BOLT

12

01643-31032

WASHER

13

21X-54-11531

COVER

|13

21X-54-11530

COVER

14

21X-54-11542

COVER

|14

21X-54-11541

COVER

15

21X-54-11750

SEAL

16

21X-54-11760

SEAL

17

21X-54-11560

SEAL

18

01010-50816

BOLT

19

01010-50820

BOLT

20

01643-30823

WASHER

21

21X-54-11522

COVER

|21

21X-54-11521

COVER

22

21X-54-11810

SEAL

23

09412-00003

SEAL

24

21X-54-11791

COVER

|24

21X-54-11790

COVER

25

21X-54-11830

SEAL

26

01010-50816

BOLT

27

01643-30823

WASHER

28

205-60-71220

LOCK ASS'Y,(FOR VANDALISM PROTECTION)
