Запчасти Komatsu PC380LC-7K ОСНОВН. КЛАПАН (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
№
Артикул
Название
Примечание
Количество
|1
723-48-26102
CONTROL VALVE
|1
723-40-66300
VALVE ASS'Y
1
CASE
2
SEAT
3
SEAT
4
BALL
5
PLUG
|6
723-90-76501
VALVE ASS'Y,SUCTION AND SAFETY
6
SLEEVE
7
SLEEVE
8
POPPET
9
SEAL
10
PISTON
11
SLEEVE
12
POPPET
13
UNION
14
PISTON
15
SPRING
16
SPRING
17
SPRING
18
SEAL
19
SEAL
20
07000-13024
O-RING
21
O-RING
22
NUT
23
NUT
24
HOLDER
25
O-RING
26
SPRING
27
O-RING
|28
723-90-61700
VALVE ASS'Y,SUCTION AND SAFETY
28
SLEEVE
29
SLEEVE
30
POPPET
31
PISTON
32
PLUG
33
POPPET
34
SPACER
35
SPRING
36
SPRING
37
SPRING
38
SEAL
39
SEAL
40
07000-13024
O-RING
41
O-RING
42
O-RING
43
NUT
44
NUT
Выбрано товаров: 48
