Запчасти Komatsu PC380LC-7K ОСНОВН. КЛАПАН (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-26102

CONTROL VALVE

|1

723-40-91200

VALVE ASS'Y,SUCTION AND SAFETY

1

SLEEVE

2

SLEEVE

3

POPPET

4

PISTON

5

PLUG

6

POPPET

7

SPACER

8

SPRING

9

SPRING

10

SPRING

11

SEAL

12

SEAL

13

709-25-11390

O-RING

14

O-RING

15

O-RING

16

NUT

17

NUT

|18

723-90-69100

VALVE ASS'Y,SUCTION AND SAFETY

18

SLEEVE

19

SLEEVE

20

POPPET

21

PISTON

22

PLUG

23

POPPET

24

SCREW

25

SPACER

26

SPRING

27

SPRING

28

SPRING

29

SEAL

30

SEAL

31

O-RING

32

07002-13634

O-RING

33

O-RING

34

NUT

|35

723-90-76201

VALVE ASS'Y,SUCTION AND SAFETY

35

SLEEVE

36

SLEEVE

37

POPPET

38

SEAL

39

PISTON

40

SLEEVE

41

POPPET

42

UNION

43

PISTON

44

SPRING

45

SPRING

46

SPRING

47

SEAL

48

SEAL

49

07000-13024

O-RING

50

O-RING

51

NUT

52

NUT

53

HOLDER

54

O-RING

55

SPRING

56

O-RING

|57

723-40-85100

VALVE ASS'Y,SUCTION

57

SLEEVE

58

VALVE

59

SPRING

60

SEAL

61

709-25-11390

O-RING
