Запчасти Komatsu PC380LC-7K ЦИЛИНДР РУКОЯТИ(КЛАПАН ПЕРЕГРУЗКИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XY330

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0A450

ARM CYLINDER ASS'Y

1

707-13-16710

CYLINDER

2

707-76-10310

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11360

ROD

5

707-76-10310

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-71-32800

COLLAR

8

707-35-91640

RING,BACK-UP (KIT)

9

07000-15150

O-RING (KIT)

10

707-71-61130

PLUNGER

11

707-71-70290

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

07020-00000

FITTING,GREASE

15

707-27-16920

HEAD

16

198-63-94170

SEAL,DUST (KIT)

17

07179-13126

RING,SNAP

18

707-52-90850

BUSHING

19

707-51-11030

PACKING,ROD (KIT)

20

707-51-11640

RING,BUFFER (KIT)

21

707-35-91640

RING,BACK-UP (KIT)

22

07000-15150

O-RING (KIT)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-36-16580

PISTON

26

01310-01216

SCREW

27

707-44-16180

RING,PISTON (KIT)

28

707-39-16120

RING,WEAR (KIT)

29

707-44-16910

RING

30

07001-05100

RING,BACK-UP (KIT)

31

07000-15100

O-RING (KIT)

31A

707-83-13010

VALVE

31B

07750-01628

SPRING

31C

707-87-14070

PLUG

31D

07002-12034

O-RING (KIT)

32

707-86-11610

BLOCK

33

01435-01095

BOLT

34

07000-13035

O-RING (KIT)

35

707-88-33040

CAP,(FOR SHIPPING)

36

07371-31049

FLANGE,SPLIT (FOR SHIPPING)

37

07372-21035

BOLT,(FOR SHIPPING)

38

01643-51032

WASHER,(FOR SHIPPING)

|K

707-99-67090

SERVICE KIT
