Запчасти Komatsu PC380LC-7K ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC380LC-7K - ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
5
6
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
29
30
30
31
31A
31B
31C
31D
32
33
34
35
36
36
37
38
39
40
41
41
42
42
43
43
44
44
45
46
47
48

Артикул

Название

Примечание

Количество

G1

707-01-XZ980

CYLINDER GROUP,(FINAL COATING)

|G1

707-01-XA450

CYLINDER GROUP

|1

707-01-0A450

ARM CYLINDER ASS'Y

1

707-13-16710

CYLINDER

2

707-76-10310

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11360

ROD

5

707-76-10310

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-71-32800

COLLAR

8

707-35-91640

RING,BACK-UP (KIT)

9

07000-15150

O-RING (KIT)

10

707-71-61130

PLUNGER

11

707-71-70290

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

07020-00000

FITTING,GREASE

15

707-27-16920

HEAD

16

198-63-94170

SEAL,DUST (KIT)

17

07179-13126

RING,SNAP

18

707-52-90850

BUSHING

19

707-51-11030

PACKING,ROD (KIT)

20

707-51-11640

RING,BUFFER (KIT)

21

707-35-91640

RING,BACK-UP (KIT)

22

07000-15150

O-RING (KIT)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-36-16580

PISTON

26

01310-01216

SCREW

27

707-44-16180

RING,PISTON (KIT)

28

707-39-16120

RING,WEAR (KIT)

29

707-44-16910

RING

30

07001-05100

RING,BACK-UP (KIT)

31

07000-15100

O-RING (KIT)

31A

707-83-13010

VALVE

31B

07750-01628

SPRING

31C

707-87-14070

PLUG

31D

07002-12034

O-RING (KIT)

32

707-86-11600

TUBE

33

707-86-11610

BLOCK

34

01435-01055

BOLT

35

01435-01095

BOLT

36

07000-13035

O-RING (KIT)

37

707-88-22740

BRACKET

38

707-88-21380

BAND

39

207-63-64190

BRACKET

40

707-88-21390

BAND

41

01435-01235

BOLT

42

07283-23442

CLIP

43

01643-31032

WASHER

44

01599-01011

NUT

45

707-88-33040

CAP,(FOR SHIPPING)

46

07371-31049

FLANGE,SPLIT (FOR SHIPPING)

47

07372-21035

BOLT,(FOR SHIPPING)

48

01643-51032

WASHER,(FOR SHIPPING)

|K

707-99-67090

SERVICE KIT

Выбрано товаров: 56
