Запчасти Komatsu PC380LC-6K ОСНОВН. КЛАПАН (8 СЕКЦ.) (/) ГИДРАВЛИКА
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
39
39
40
40
40
41
42
№
Артикул
Название
Примечание
Количество
|1
723-48-16101
CONTROL VALVE
|1
723-41-03500
BODY SUB ASS'Y
|1
723-40-66300
VALVE ASS'Y
1
CASE
2
SEAT
3
SEAT
4
BALL
5
PLUG
|6
709-70-74700
VALVE ASS'Y,SUCTION AND SAFETY
6
SLEEVE
7
SLEEVE
8
POPPET
9
PISTON
10
PLUG
11
POPPET
12
SCREW
13
SPRING
14
SPRING
15
SPRING
16
SEAL
17
SEAL
18
709-25-11390
O-RING
19
O-RING
20
O-RING
21
NUT
|22
723-46-48100
VALVE ASS'Y
22
SLEEVE
23
VALVE
24
SEAT
25
POPPET
26
PLUG
27
SCREW
28
NUT
29
NUT
30
SPRING
31
SPRING
32
PLATE
33
CAP
34
SEAL
35
SEAL
36
700-93-11320
O-RING
37
723-46-41950
RING
38
07002-13634
O-RING
39
O-RING
40
RING
41
O-RING
42
RING,BACK-UP
Выбрано товаров: 47
