Запчасти Komatsu PC360LC ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (ДЛЯ .M РУКОЯТЬ) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-F1-00130

CYLINDER ASSEMBLY

1

707-13-15261

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL, DUST (KIT)

4

07020-00000

FITTING, GREASE

5

721-58-11110

ROD

6

207-63-76170

BUSHING

7

207-70-72120

SEAL, DUST (KIT)

8

07020-00000

FITTING, GREASE

9

707-27-15650

HEAD

10

707-56-11740

SEAL, DUST (KIT)

11

07179-13126

RING, SNAP

12

707-52-90850

BUSHING

13

707-75-11040

RING, SNAP

14

707-51-11030

PACKING, ROD (KIT)

15

707-51-11650

RING, BUFFER (KIT)

16

707-35-91660

RING, BACK-UP (KIT)

17

07000-15140

O-RING (KIT)

18

707-88-81530

BOLT

19

707-88-75310

WASHER

20

707-36-15260

PISTON

21

01310-01216

SCREW

22

707-44-15150

RING, PISTON (KIT)

23

707-39-15110

RING, WEAR (KIT)

24

707-44-15911

RING

25

07001-05100

RING, BACK-UP (KIT)

26

07000-15100

O-RING (KIT)

27

707-86-11631

TUBE

28

207-63-73180

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING (KIT)

32

707-88-22690

BRACKET

33

707-88-21420

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

707-88-33040

CAP

40

07371-31049

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$45

707-99-59750

SERVICE KIT
