Запчасти Komatsu PC360LC-10 КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) КОНЕЧНАЯ ПЕРЕДАЧА

|$0

207-27-00480

Final Drive Assembly

|$1

708-8H-00370

Motor Assembly

1

708-8H-32130

Shaft

2

708-8H-32150

Bearing

3

708-8H-32170

Bearing

4

708-8H-05050

Spacer Kit

5

708-1F-12281

Seal, Oil

6

708-8H-32160

Spacer

7

04065-07825

Ring, Snap

|$16

708-8H-04830

Cylinder Block Assembly

10

708-18-13230

Pin

11

708-8H-33540

Pin

12

708-2H-23141

Seat

13

708-8H-33760

Spring

14

04065-05820

Ring, Snap

15

708-8H-33520

Guide, Retainer

16

708-8H-33530

Retainer, Shoe

17

708-8H-33390

Piston Subassembly

18

708-8H-33490

Cam, Rocker

19

708-8H-33380

Ball, Retainer

20

708-8H-34240

Piston

21

708-8H-34250

Spring

22

708-8H-34260

Spring

23

708-8H-35220

Plate

24

708-8H-35230

Disc

25

708-8H-35190

Piston, Brake

26

07000-15175

O-Ring

27

07001-05175

Ring, Back-Up

28

07000-15195

O-Ring

29

07001-05195

Ring, Back-Up

30

708-8H-35150

Spring

31

708-8H-35240

Ring, Brake
