Запчасти Komatsu PC360LC-10 K-A КОНДИЦ. ВОЗДУХА COMPLETE ASSEMBLY OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

2A5-979-1112

AIR CONDITIONER

|$1

ND443120-1961

COOLING UNIT ASSEMBLY

1

ND245450-8520

CASE

2

ND245450-8530

CASE

3

ND245450-8540

CASE

4

ND116577-0970

PLATE

5

ND446010-5360

EVAPORATOR

|$7

ND447610-0630

EVAPORATOR ASSEMBLY

6

ND949142-0020

O-RING

7

ND949142-0030

O-RING

8

ND447500-3750

VALVE, EXPANSION

9

ND146636-7450

PACKING

10

ND446260-2160

TUBE

11

ND949142-0020

O-RING

12

ND949142-0030

O-RING

13

ND949046-3610

BOLT

14

ND949046-3100

BOLT

15

ND146363-7460

PACKING

16

ND445021-3941

PLUG

17

ND116420-7450

CORE SUBASSEMBLY

18

ND100775-8400

THERMISTOR ASSEMBLY

19

ND246790-2060

CLAMP

20

ND116740-4980

DOOR ASSEMBLY

21

ND116740-4990

DOOR ASSEMBLY

22

ND116782-6690

LEVER

23

ND116782-6700

LEVER

24

ND116780-5651

LEVER SUBASSEMBLY

25

ND116577-0981

PLATE

26

ND116577-0990

PLATE

27

ND063800-0300

SERVO MOTOR ASSEMBLY

28

ND0949001-1730

SCREW, TAPPING

29

ND0146636-7560

PACKING
