Запчасти Komatsu PC360LC-10 B9999- ЗАКРЫТ.D CRANKКОРПУС ВЕНТИЛЯТОРILATION (CCV) W/ХЛАДАГЕНТ CIRCULATION (/) ДВИГАТЕЛЬ

1

6746-21-7520

HOSE

2

6746-21-7530

HOSE

3

6746-21-7540

HOSE

4

6746-21-7550

BLOCK

5

6746-21-7560

BRACKET

6

6252-11-2900

SENSER

7

600-331-1930

SCREW

8

01640-20508

WASHER

9

6746-21-7570

HOSE

10

6746-21-7580

HOSE

11

6746-81-9310

HARNESS

12

6746-11-5720

COVER

13

6746-11-5710

COVER

14

6746-21-7590

BRACKET

15

6746-11-5730

BRACKET

16

07281-00197

CLAMP

17

6745-61-8110

BUSHING, REDUCING PIPE

18

6746-21-7510

JOINT

19

07005-01212

WASHER

20

6136-71-5540

JOINT

21

07206-30812

JOINT

22

07005-01212

WASHER

23

3999620

STUD

24

01584-00806

NUT

25

07281-00419

CLAMP

26

04434-52312

CLIP

27

2A5-01-11580

CUSHION

28

01024-81225

BOLT

29

01024-81220

BOLT

30

01024-81220

BOLT

31

01024-80820

BOLT

32

600-051-1100

CLIP

33

600-051-3100

CLIP

34

6162-73-6770

SPACER

35

01010-80895

BOLT

36

01643-30823

WASHER

37

01024-80816

BOLT

38

6252-81-9640

CLIP

39

01024-81025

BOLT

40

01584-01008

NUT

41

600-332-2310

VENTILATOR

N/I

07005-01212

GASKET
