Запчасти Komatsu PC360LC-10 K-A КАБИНА ПРАВ. КОНСОЛЬ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

2A5-43-11542

FRAME

2

01010-D1235

BOLT

3

01643-71232

WASHER

4

2A5-43-12460

PLATE

5

2A5-43-11862

BRACKET

6

01010-80616

BOLT

7

01643-30623

WASHER

8

22U-43-23251

SHEET

9

22U-43-23290

CLIP

10

2A5-43-11582

COVER

11

01245-00616

SCREW, HEXAGON SOCKET HEAD

12

01643-70623

WASHER

13

2A5-43-12410

COLLAR

14

2A5-43-11592

COVER

15

01245-00616

SCREW, HEXAGON SOCKET HEAD

16

01643-70623

WASHER

17

2A5-43-12410

COLLAR

18

2A5-43-11611

COVER

19

01245-00616

SCREW, HEXAGON SOCKET HEAD

20

01643-70623

WASHER

21

2A5-43-12410

COLLAR

22

2A5-43-12271

SHEET

23

2A5-43-12280

SHEET

24

2A5-43-12320

SHEET

25

2A5-43-12311

SHEET

26

2A5-43-12430

SHEET

27

2A5-43-12530

TRIM

28

08086-20000

SWITCH, STARTING

29

20Y-43-41740

PLATE

30

20Y-43-41750

WASHER

31

20Y-43-41790

WASHER

32

20Y-43-41671

HOSE

33

08034-20519

CLAMP, HOSE

34

22U-06-22380

POTENTIOMETER

35

22U-06-22460

SPRING

36

20Y-43-41781

KNOB, FUEL CONTROL DIAL

37

20Y-06-42110

SWITCH, SWING LOCK

38

20Y-06-42121

SWITCH, LIGHT

39

21T-06-33760

SWITCH, MACHINE PUSH-UP

40

20Y-06-42190

COVER

41

208-06-41150

WIRING HARNESS

42

01023-10508

SCREW

43

01601-20513

WASHER

44

22U-43-23260

CLIP

45

01010-81020

BOLT

46

01643-31032

WASHER
