Запчасти Komatsu PC360LC-10 K-A КАБИНА ВЕНТИЛЯТОР В КРЫШЕ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

2A5-53-12411

ROOF

2

2A5-53-11K11

HINGE, WELDED

3

2A5-53-11K21

HINGE, WELDED

4

01584-30806

NUT

5

20Y-53-11921

COVER

6

09416-10200

BUTTON

7

2A5-53-12840

PLATE

8

20Y-53-11790

SEAL

9

2A5-53-11471

SEAL

10

20Y-54-14590

HANDLE

11

01245-00616

SCREW, HEXAGON SOCKET HEAD

12

01643-70623

WASHER

13

2A5-53-12930

LOCK ASSEMBLY

14

20Y-53-11781

KNOB

15

01435-40610

BOLT

16

20Y-53-11931

COVER

17

208-53-22161

GAS SPRING

18

2A5-53-12530

PIN, SNAP

19

20Y-53-11771

STRIKER

20

01245-00820

SCREW, HEXAGON SOCKET HEAD

21

20Y-54-52651

SPACER

22

20Y-53-11861

SEAL

23

01643-70823

WASHER

24

01245-00620

SCREW, HEXAGON SOCKET HEAD

25

01643-70623

WASHER

26

20Y-54-52651

SPACER
