Запчасти Komatsu PC360LC-10 H-7A ОСНОВН. НАСОС COMPLETE ПОРШЕНЬ НАСОС ASSEMBLY (7/) ГИДРАВЛИКА

|$0

708-2G-00171

PUMP ASSEMBLY

|$1

708-2G-01170

PUMP SUBASSEMBLY

1

708-2G-12190

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

|$5

NSS

WASHER, T=3.0 MM

|$6

NSS

WASHER, T=3.1 MM

|$7

NSS

WASHER, T=3.2 MM

4

708-1F-12270

RING, SNAP

|$9

708-2G-04272

CYLINDER BLOCK ASSEMBLY

5

NSS

CYLINDER BLOCK

6

NSS

PLATE, VALVE

7

708-18-13230

PIN

8

04065-05520

RING, SNAP (HOLE SIDE)

9

708-2G-13131

SEAT

10

708-2G-13152

SPRING

11

708-2G-13141

SEAT

12

708-2G-13510

GUIDE, RETAINER

13

708-2H-23360

PIN

14

708-2G-13341

RETAINER, SHOE

15

708-2G-13370

PISTON SUBASSEMBLY

|$21

708-2G-04670

CRADLE SUBASSEMBLY

16

NSS

CRADLE

17

NSS

CAM, ROCKER

18

04020-01434

PIN, DOWEL

19

07000-B1009

O-RING

20

01252-61230

BOLT
