Запчасти Komatsu PC360LC-10 H-8A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН COMPLETE ASSEMBLY (8/) ГИДРАВЛИКА

|$1

723-48-26800

CONTROL VALVE

|$2

723-40-87800

VALVE ASSEMBLY

1

NSS

BODY

2

NSS

SPOOL

3

723-40-87650

SPRING

4

NSS

SLEEVE

5

NSS

FILTER

6

NSS

SPRING

7

NSS

PLUG

8

723-40-87670

O-RING

9

723-40-87170

O-RING

10

07000-13035

O-RING

11

07000-11008

O-RING

12

07040-11007

PLUG

13

07002-11023

O-RING

14

702-21-60900

VALVE, PILOT

15

700-80-61260

O-RING

16

723-11-19960

O-RING

17

702-21-54180

Screw

18

702-21-54910

O-RING

19

01252-60635

BOLT, HEXAGON SOCKET HEAD

20

01252-60845

BOLT, HEXAGON SOCKET HEAD

21

01252-61075

BOLT, HEXAGON SOCKET HEAD

22

07000-13038

O-RING

23

07000-11010

O-RING
