Запчасти Komatsu PC360LC-10 РУКОЯТЬ, ЦИЛИНДР КОВША (№7-) РУКОЯТЬ, MM

|$0

707-E1-00710

Cylinder Assembly

1

721-13-14060

Cylinder

2

721-58-10410

Rod, Piston

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K06)

5

07020-00000

Fitting, Grease

6

207-63-76170

Bushing

7

207-70-72120

Seal, Dust, (Kit : K06)

8

07020-00000

Fitting, Grease

9

707-27-14690

Head, Cylinder

10

707-56-10740

Seal, Dust, (Kit : K06)

11

07179-13114

Ring, Snap

12

707-52-90781

Bushing

13

707-51-10860

Packing, Rod, (Kit : K06)

14

707-51-10650

Ring, Buffer, (Kit : K06)

15

707-35-31310

Ring, Back-up, (Kit : K06)

16

07000-B5130

O-ring, (Kit : K06)

17

01010-81875

Bolt

18

707-41-11840

Washer

19

707-75-10160

Ring, Snap

20

707-36-14650

Piston

21

707-44-14150

Ring, Piston, (Kit : K06)

22

707-39-14110

Ring, Wear, (Kit : K06)

23

707-35-30900

Ring, Back-up, (Kit : K06)

24

07000-B5090

O-ring, (Kit : K06)

25

707-44-14910

Ring

26

01310-01216

Screw

27

707-86-00840

Tube

28

707-86-00850

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K06)

32

707-88-51130

Bracket

33

07372-21240

Bolt

34

01643-51232

Washer

35

707-88-10150

Clamp

36

01010-81245

Bolt

37

01643-31232

Washer

38

07371-31049

Flange, Split

39

707-88-33040

Cap

40

07372-21035

Bolt

41

01643-51032

Washer
