Запчасти Komatsu PC360LC-10 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№7-79) ЦИЛИНДР СТРЕЛЫ

|$0

707-E1-00680

Cylinder Assembly

1

721-13-14050

Cylinder

2

721-58-10400

Rod, Piston

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K03)

5

07020-00000

Fitting, Grease

6

07043-00108

Plug, Taper

7

707-76-10290

Bushing

8

07145-00100

Seal, Dust, (Kit : K03)

9

707-71-35220

Collar

10

707-35-31310

Ring, Back-up, (Kit : K03)

11

07000-B5130

O-ring, (Kit : K03)

12

707-71-71060

Plunger

13

707-27-14690

Head, Cylinder

14

707-56-10740

Seal, Dust, (Kit : K03)

15

07179-13114

Ring, Snap

16

707-52-90781

Bushing

17

707-51-10030

Packing, Rod, (Kit : K03)

18

707-51-10650

Ring, Buffer, (Kit : K03)

19

707-35-31310

Ring, Back-up, (Kit : K03)

20

07000-B5130

O-ring, (Kit : K03)

21

01010-81875

Bolt

22

707-41-11840

Washer

23

707-75-10160

Ring, Snap

24

707-36-14650

Piston

25

707-44-14150

Ring, Piston, (Kit : K03)

26

707-39-14110

Ring, Wear, (Kit : K03)

27

707-35-30900

Ring, Back-up, (Kit : K03)

28

07000-B5090

O-ring, (Kit : K03)

29

707-44-14910

Ring

30

01310-01216

Screw

31

707-86-00820

Tube

32

207-63-54680

Tube

33

207-63-54590

Bracket

34

07372-21060

Bolt

35

01643-51032

Washer

36

07000-13035

O-ring, (Kit : K03)

37

707-88-21370

Band

38

07372-21240

Bolt

39

01643-51232

Washer

40

07283-33442

Clip, Pipe

41

01597-01009

Nut

42

01643-31032

Washer

43

01010-81025

Bolt

44

01643-31032

Washer

45

07371-31049

Flange, Split

46

707-88-33040

Cap

47

07372-21035

Bolt

48

01643-51032

Washer
