Запчасти Komatsu PC360LC-10 НАСОС АВТОМАТИЧ. ЗАПРАВКИ ТОПЛИВА НАСОС АВТОМАТИЧ. ЗАПРАВКИ ТОПЛИВА

1

20Y-04-K2082

Pump

2

20Y-04-K2450

Valve Assembly

3

20Y-04-K2351

Hose

4

208-04-42170

Hose

5

206-04-31241

Bracket

6

01010-81225

Bolt

7

01643-31232

Washer

8

207-04-41420

Bracket

9

01010-80620

Bolt

10

01643-30623

Washer

11

01010-81225

Bolt

12

01643-31232

Washer

13

07289-00035

Clamp

14

07289-00035

Clamp

15

113-899-7950

Clip

16

01010-81225

Bolt

17

01643-31232

Washer

18

20Y-04-K3081

Switch Assembly

19

07000-13032

O-ring

20

01010-80616

Bolt

21

01643-30623

Washer

22

04434-51012

Clip

23

01010-81225

Bolt

24

01643-31232

Washer

24

208-06-42120

Box, Control

25

01010-80820

Bolt

26

01643-30823

Washer

27

208-06-42130

Cover

28

208-06-42140

Gasket

29

208-06-42160

Plate

30

20Y-00-K2040

Plate

31

20Y-04-K1090

Switch

32

20Y-04-K4090

Switch

33

01010-81225

Bolt

34

01643-31232

Washer

35

09651-A0481

Plate, Warning, Read Manual Before Operating

36

207-04-41410

Bracket

37

01010-81225

Bolt

38

01643-31232

Washer

39

04434-51012

Clip

40

207-06-41450

Wiring Harness

41

207-01-41611

Bracket
