Запчасти Komatsu PC360LC-10 ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ, СТРЕЛА ANTI-DROP КЛАПАН (/) ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ

|$0

702-21-08701

Valve, Pilot

1

Valve Body

2

Spool

3

702-21-39410

Case

4

Retainer, T=2.0mm

4

Retainer, T=2.3mm

4

Retainer, T=1.7mm

5

702-21-39430

Flange

6

702-21-39440

Spring

7

702-21-39330

Spring

8

709-62-31280

O-ring

9

702-21-39450

O-ring

10

702-21-38480

Plug

11

01252-60830

Bolt

12

01252-60835

Bolt, Hexagon Socket Head

13

01252-60820

Bolt, Hexagon Socket Head

14

07000-13028

O-ring

15

Valve

16

709-94-91751

Spring

17

700-93-11320

O-ring

18

700-93-11330

Ring, Back-up

19

723-40-91500

Valve Assembly, Relief

20

700-80-64220

Ring, Back-up

21

700-22-11410

O-ring

22

709-25-11390

O-ring
