Запчасти Komatsu PC360LC-10 ОСНОВН. ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (7/) ОСНОВН. ПОРШЕНЬ НАСОС

|$0

708-2G-00140

Pump Assembly, Piston

|$1

708-2G-01140

Pump Subassembly

1

708-2G-12190

Shaft

2

708-2G-12251

Bearing

3

708-2G-05010

Washer Kit

3

Washer, T=3.0mm

3

Washer, T=3.1mm

3

Washer, T=3.2mm

4

708-1F-12270

Ring, Snap

|$9

708-2G-04272

Block Assembly

5

Cylinder Block

6

Plate, Valve

7

708-18-13230

Pin

8

04065-05520

Ring, Snap, for Hole Side

9

708-2G-13131

Seat

10

708-2G-13152

Spring

11

708-2G-13141

Seat

12

708-2G-13510

Guide, Retainer

13

708-2H-23360

Pin

14

708-2G-13341

Retainer, Shoe

15

708-2G-13370

Piston Subassembly

|$21

708-2G-04670

Cradle Subassembly

16

Cradle

17

Cam, Rocker

18

04020-01434

Pin, Dowel

19

07000-B1009

O-ring

20

01252-61230

Bolt
