Запчасти Komatsu PC360-8M0 РУКОЯТЬ(ЦИЛИНДР КОВША) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

|$1

707-F1-X2190

CYLINDER ASSEMBLY

1

721-13-14060

CYLINDER

2

721-58-10410

ROD, PISTON

3

707-76-90130

BUSHING

4

07145-00090

SEAL, DUST\((K22)\)

5

07020-00000

FITTING, REASE

6

207-63-76170

BUSHING

7

207-70-72120

SEAL, DUST\((K22)\)

8

07020-00000

FITTING, REASE

9

707-27-14690

HEAD, CYLINDER

10

707-56-10740

SEAL, DUST\((K22)\)

11

07179-13114

RING, SNAP

12

707-51-10860

PACKING, ROD\((K22)\)

13

707-51-10650

RING, BUFFER\((K22)\)

14

707-52-90781

BUSHING

15

07000-B5130

O-RING\((K22)\)

16

707-35-31310

RING, BACK-UP\((K22)\)

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-75-10160

RING, SNAP

20

707-36-14650

PISTON

21

707-44-14150

RING, PISTON\((K22)\)

22

707-39-14110

RING, WEAR\((K22)\)

23

707-44-14910

RING

24

07000-B5090

O-RING\((K22)\)

25

707-35-30900

RING, BACK-UP\((K22)\)

26

01310-01216

SCREW

27

707-86-16330

TUBE

28

207-63-73181

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING\((K22)\)

32

707-88-51380

BRACKET

33

707-88-21410

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

07371-31049

FLANGE, SPLIT
