Запчасти Komatsu PC360-7 СТАРТЕР(KW)(ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ]

|$0

600-863-8111

STARTING MOTOR ASS'Y,(11KW)

1

KD1-09279-0090

NUT

2

KD1-0335-08002

WASHER,SPRING

3

KD1-0330-08022

WASHER,PLAIN

4

KD1-0345-08001

WASHER,SEAL

5

KD0-23303-0020

PIN,LEVER

6

KD1-23914-0020

RING,CLIP

7

KD1-23181-0020

STOPPER,PINION

8

KD0-23120-0180

SHAFT ASS'Y

9

KD0-23310-1740

FRONT BRACKET ASS'Y

10

KD0-23500-0970

CLUTCH ASS'Y,OVER RUNNING

11

KD0-23320-0290

SHIFT LEVER ASS'Y

12

KD0-09201-0850

BEARING,BALL

13

KD0-23600-0410

CENTER BRACKET A.

14

KD0-23611-1101

BRACKET,CENTER

15

KD0-0274-06202

BOLT

16

KD1-23951-0051

PACKING

17

KD1-0400-30100

PIN,STRAIGHT

18

KD0-23100-0430

ARMATURE ASS'Y

19

KD0-47100-4651

MAGNETIC SWITCH A.

20

KD0-23200-0671

YOKE ASS'Y

21

KD0-09271-3620

NAME PLATE

22

KD1-09211-1120

O-RING

23

KD0-23740-0351

BRUSH ASS'Y

24

KD0-23750-0490

BRUSH HOLDER A.

25

KD0-47761-2681

COVER

26

KD0-47761-2691

COVER

27

KD0-09011-3140

SCREW

28

KD1-09211-0081

O-RING

29

KD0-23710-0221

BRACKET,REAR

30

KD0-09001-4380

BOLT

31

KD1-47921-0790

WASHER

32

KD0-0276-08402

BOLT

33

KD0-09057-0110

WASHER

34

KD1-23941-0040

WASHER,INSULATE

35

KD1-23921-0140

WASHER

36

KD1-23921-0130

WASHER

37

KD0-0055-05082

SCREW

38

KD0-09057-0190

WASHER

39

KD0-0020-05062

SCREW

40

KD1-0345-05001

WASHER,SEAL

41

KD1-0240-06305

BOLT

42

KD0-25000-8332

SWITCH ASS'Y

43

KD0-0270-06602

BOLT

44

KD0-47927-1390

HOLDER

45

KD0-47761-2671

COVER

46

KD1-19211-0981

O-RING

47

KD0-09006-0660

NUT

48

KD0-09006-0670

NUT

49

KD1-09257-0050

BAND

50

KD0-09275-1430

PLATE,CAUTION
