Запчасти Komatsu PC35R-8 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

\0

871070069

ENGINE, ASSY.

1

YM129004-42001

PUMP, ASSY.

3

YM129100-42051

GASKET

4

YM129100-42121

PLATE

8

YM121850-42410

SCREW

10

YM119802-49113

JOINT

11

YM23876-010000

PLUG

12

YM23876-020000

PLUG

13

YM129916-49740

PLUG

14

YM129486-42021

GASKET

15

YM129004-42040

JOINT

16

YM129486-42140

O-RING

17

YM124395-49840

GASKET

18

YM26106-080162

BOLT

19

YM26106-080602

BOLT

20

YM129403-42380

PULLEY

21

YM119831-42290

V-BELT

22

YM129436-44740

FAN

23

YM171056-49120

PLUG

24

YM26106-080122

BOLT

25

YM129155-49801

THERMOSTAT

26

YM129150-49811

GASKET

27

YM129350-49530

COVER, THERMOSTAT

28

YM129795-49551

GASKET

29

YM26106-080222

SCREW

30

YM23414-080000

GASKET

31

YM121450-42450

PLUG

32

YM121250-44901

WATER TEMPERATURE TRANSMITTER (ALARM)

33

YM124465-44950

GASKET

34

YM124465-44950

GASKET

35

YM129004-49610

PIPE, ASSY.

36

YM129004-49711

PIPE, ASSY.

37

YM119802-49730

CLAMP

38

YM124722-59050

CLAMP

39

YM129004-49620

PIPE, ASSY.

40

YM129004-49721

PIPE

41

YM124722-59050

CLAMP

42

YM119256-44760

SPACER

43

YM26106-060602

BOLT PLATED
