Запчасти Komatsu PC35R-8 ОСНОВН. КЛАПАН (8-КЛАПАН) (9/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-18-12708

CONTROL VALVE

|1

723-18-12707

CONTROL VALVE

|1

723-18-12706

CONTROL VALVE

|1

723-18-12702

CONTROL VALVE

1

723-11-18280

VALVE

2

723-11-18290

SPRING

3

723-26-15230

PLUG

4

07002-12434

O-RING

5

SPOOL

6

SEAL

7

VALVE

|7

VALVE

8

723-11-18220

SPRING

9

723-11-18250

SPRING

10

723-11-18260

SLEEVE

11

720-68-19760

O-RING

12

723-11-18150

O-RING

13

723-11-18160

RING

14

VALVE

15

VALVE

|15

VALVE

15A

VALVE

16

VALVE

|16

VALVE

17

VALVE

18

ORIFICE

19

PISTON

20

VALVE

|20

VALVE

21

VALVE

22

VALVE

23

VALVE

|23

VALVE

24

PISTON

25

SPACER

26

723-11-16230

SPRING

27

723-11-15130

SPRING

28

723-11-15110

PLUG

29

07002-11623

O-RING

30

ORIFICE

|30

ORIFICE

31

723-11-15170

SCREW

32

723-11-15180

SLEEVE

33

723-11-15190

SPRING

34

723-11-16680

PLUG

|34

723-11-16270

PLUG

35

PISTON

36

723-11-16660

SPRING

|36

723-11-16290

SPRING

37

01583-11207

NUT

38

07000-11006

O-RING

39

07001-01006

RING

40

723-11-16651

SLEEVE

41

723-11-16690

PLUG

42

07000-11006

O-RING

43

07001-01006

RING

44

01580-10605

NUT
