Запчасти Komatsu PC35R-8 РУКОЯТЬ (ДЛЯ QUICK ГИДРОМОЛОТ) (РУКОЯТЬ¤НАВЕСН.ОБОРУД. ЛИНИЯ¤ПАЛЕЦ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20S-870-0010

ARM ASS'Y

1

ARM,FIRST

2

20S-70-81290

BUSHING

3

07145-00040

SEAL,DUST

4

07020-00000

FITTING,GREASE

5

07144-10404

BUSHING

6

07145-00040

SEAL,DUST

7

07020-00000

FITTING,GREASE

8

20S-870-1610

ARM,SECOND

9

21W-70-11211

PIN

10

205-70-66580

PLATE

11

01010-81230

BOLT

12

01643-51232

WASHER

13

20S-870-1670

SPACER

14

20S-870-1150

PIN

15

20T-870-1190

PIN,RING

16

20S-870-1230

HOSE

17

21X-70-21280

GROMMET

18

203-62-32450

COVER

19

08034-00519

BAND

20

21X-70-21210

PIN

|20

20S-70-81150

PIN

21

04082-00212

LOCK

22

01010-81230

BOLT

23

01643-31232

WASHER

24

20S-70-81780

SPACER¤ 1.0MM

|24

20R-70-11260

SPACER¤ 1.0MM

25

20S-70-71240

PIN

26

04082-00212

LOCK

27

01010-81230

BOLT

28

01643-31232

WASHER

29

20T-70-81720

SPACER¤ 1.0MM

|29

20R-70-11270

SPACER¤ 1.0MM

30

20S-870-1651

COLLAR

31

20S-870-1660

BOLT

32

01643-33080

WASHER

33

01580-13024

NUT

34

20S-970-7330

SHIM¤ 0.5MM

35

113-06-23220

COVER

36

20S-63-X2424

CYLINDER ASS'Y

|36

20S-63-X2423

CYLINDER GROUP,BUCKET
