Запчасти Komatsu PC35R-8 DELUXE ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070046

ENGINE, ASSY.

1

YM198220-51870

CLAMP

2

YM24311-000120

O-RING

3

YM23065-160800

PIPE

4

YM124736-07900

LIFTER

5

YM26106-080142

BOLT

6

YM129001-11700

HEAD,ASSY.

7

HEAD, ASSY.

9

YM120130-11860

GUIDE VALVE

11

YM129150-11810

GUIDE VALVE

13

YM26216-060202

STUD

14

YM27241-400000

PLUG

15

YM129100-11100

VALVE, INLET

16

YM129100-11110

VALVE EXHAUST

17

YM129795-11120

SPRING, VALVE

18

YM129795-11180

RETAINER, SPRING

19

YM27310-080000

COTTER

20

YM121400-11340

SEAL, VALVE EXHAUST

21

YM124460-11340

SEAL, VALVE STEM

22

YM129150-11370

CAP VALVE

23

YM119625-11870

PROTECTION, NOZZLE

24

YM119625-11880

SEAT, NOZZLE

25

YM119625-11900

RETAINER

26

YM129155-11241

ROCKER SHAFT, ASSY.

27

YM129155-11260

SUPPORT

28

YM129155-11270

SUPPORT

29

YM129150-11280

SPRING

30

YM129150-11290

SHAFT

33

YM729402-11650

ROCKER SHAFT

34

YM129150-11230

SCREW

36

YM129150-11750

NUT

37

YM26226-080182

STUD

38

YM22351-060012

PEG

39

YM26106-080252

SCREW

40

YM26106-080502

SCREW

41

YM26366-060002

NUT

42

YM729132-11521

COVER, ASSY.

43

YM124160-01751

PLUG

44

YM129150-03020

COVER, BREATHER

45

YM129150-03070

SPLASH-GUARD

46

YM129150-03080

PROTECTION

48

YM129150-11310

GASKET

49

YM24311-000320

O-RING

50

YM24341-000500

O-RING

51

YM26106-080162

BOLT

52

YM124160-11360

PLUG

53

YM121750-59890

RETAINER
