Запчасти Komatsu PC35MRX-1A КАБИНА (/) (ДВЕРЬ /)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$5

22F-54-00063

CAB ASS'Y

|$6

22F-54-00062

CAB ASS'Y

|$7

22F-54-00061

CAB ASS'Y

|$8

22F-54-00060

CAB ASS'Y

|$10

22M-54-00022

DOOR ASS'Y

1

22M-54-14310

DOOR

2

22M-54-14340

GLASS,UPPER

3

22M-54-14350

GLASS,LOWER

4

20U-54-24411

DAM,(L=3850)

5

20U-54-24421

DAM,(L=500)

6

20U-54-24431

TRIM

7

22M-54-16350

SEAL

8

22M-54-14470

HANDLE

9

22M-54-14430

COVER

10

21W-54-34480

PACKING

11

22M-54-16340

CLIP

12

01023-20612

SCREW

13

21J-54-16630

GRIP

14

01220-40512

SCREW

15

01601-20513

WASHER

16

22M-54-16323

UPPER ROLLER ASS'Y

17

01010-80816

BOLT

18

01643-30823

WASHER

19

20U-54-24923

ROLLER ASS'Y

20

01010-D0816

BOLT

21

01643-70823

WASHER

22

20U-54-24934

ROLLER ASS'Y,LOWER

23

01010-D0816

BOLT

24

01643-70823

WASHER

25

22M-54-14950

BRACKET

26

22M-54-14460

BRACKET

27

01010-D1225

BOLT

28

01643-71232

WASHER

29

20U-54-25321

STRIKER

30

01010-80610

BOLT

31

01641-20608

WASHER

32

20U-54-25341

SHIM, 1.0MM

33

22M-54-14D70

SHEET
