Запчасти Komatsu PC35MRX-1A MULTI PATTERN ( АКТУАТОР) (КЛАПАН)(№9-) ГИДРАВЛИКА

|$5

22F-62-17301

VALVE ASS'Y

|$6

22F-62-17300

VALVE ASS'Y

1

21U-62-34573

LEVER

2

22L-98-11522

LEVER

2

22L-98-11521

PLATE

3

21U-62-34590

PLATE

4

01252-70620

BOLT

5

01643-30623

WASHER

6

21U-62-34690

COVER

7

01252-60620

BOLT

8

07016-00306

SEAL

9

203-62-58950

BODY

10

07000-03028

O-RING

11

07000-02060

O-RING

12

22F-62-13250

PLUG

13

04260-00793

BALL

14

700-84-11750

SPRING

15

22M-62-14210

SHAFT

16

203-62-58980

COVER

17

01252-60616

BOLT

18

01252-70612

BOLT

19

01643-30623

WASHER

20

21U-62-34581

BOLT

21

01640-20816

WASHER

22

04050-12015

PIN

23

07049-01215

PLUG

24

21U-62-38310

ELBOW

25

21A-62-12360

NIPPLE

26

07040-11409

PLUG

27

07002-11423

O-RING

28

22F-62-13151

HOSE, 280MM

29

22F-62-13171

HOSE, 380MM

30

22F-62-13181

HOSE, 430MM

31

22F-62-13191

HOSE, 480MM

32

08210-01203

SPIRAL TUBE

33

08210-01202

SPIRAL TUBE

34

08210-01201

SPIRAL TUBE

35

21U-62-34710

BAND, YELLOW

36

21U-62-34720

BAND, BLACK

37

21U-62-34730

BAND, GREEN

38

21U-62-34740

BAND, ORANGE
