Запчасти Komatsu PC35MR-3 МЕХАНИЗМ ПОВОРОТА И МОТОР, ВНУТР. ЧАСТИ, МОТОР ПОВОРОТА (/) (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

22L-26-21003

Swing Machinery Assembly

|$1

708-7R-00360

Motor Assembly

|$2

Motor Subassembly

1

708-7R-11650

Plate, Swash

2

708-7R-11730

Washer

3

702-21-54930

Filter

|$6

708-7R-04130

Housing Subassembly

4

Housing

5

Plug

6

708-7R-11220

Plug

7

07002-11223

O-ring

8

708-7R-11210

Valve

9

722-10-91130

Spring

10

708-7R-11290

Plug

11

07002-11823

O-ring

12

431-40-11210

O-ring

13

720-68-19610

Pin

14

01252-61230

Bolt, Hexagon Socket Head

15

708-7R-12130

Shaft

16

708-7R-12140

Bearing

17

708-7R-12150

Bearing

18

04065-04218

Ring, Snap

19

708-7R-13130

Cylinder Block

20

708-7R-13260

Plate, Valve

21

720-68-19610

Pin

22

708-7R-13540

Pin

23

708-7R-13530

Washer

24

708-7R-13560

Spring

25

04065-03012

Ring, Snap

26

708-7R-13590

Guide, Retainer

27

708-7R-13370

Retainer, Shoe, Shoe

28

708-7R-13320

Piston Subassembly

29

708-7R-13420

Plate

30

708-7R-15131

Plate

31

708-7R-15122

Disc

32

708-7R-15211

Piston

33

07000-12115

O-ring

34

07000-12085

O-ring

35

708-7R-15221

Ring, Brake

36

07000-12100

O-ring

37

708-7R-15230

Spring
