Запчасти Komatsu PC35MR-2 ЛЕВ. СЕРВОУПРАВЛ. (ДЛЯ НАВЕСА) СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА

1

22M-43-21291

STOPPER

2

01010-D0820

BOLT

3

01643-10823

WASHER

4

22M-43-R1551

LEVER

5

04205-10830

PIN

6

04050-12015

PIN, COTTER

7

21U-43-32430

BUSHING

8

22B-54-15560

STOPPER

9

01580-11008

NUT, STOP

10

22M-43-21111

HOUSING

11

22M-54-22111

COVER

12

01252-70616

BOLT

13

01643-10623

SPRING WASHER

14

22M-43-21660

GAS SPRING

15

04205-30822

PIN

16

04050-12015

PIN, COTTER

17

01643-10823

WASHER

18

22M-43-21151

PIN

19

01010-D0612

BOLT

20

01643-10623

SPRING WASHER

21

01643-10623

SPRING WASHER

22

22M-54-R2131

COVER

\22

22M-43-21630

LEVER, ASSY.

23

22M-43-21640

LEVER

\23

20Y-43-22620

KNOB

24

01370-10308

BOLT

25

20Y-43-22630

KNOB, L.H.

26

20Y-43-22421

INSERT

27

20Y-43-22250

COLLAR

28

20Y-43-22261

BOOT

29

20Y-43-22370

BOOT

30

600-411-1280

NUT

31

01252-71025

BOLT

32

01643-11032

WASHER

33

22M-43-R1541

LEVER

34

06124-01616

BEARING

35

22L-09-R3770

KNOB

36

37A-09-4P119

PIN

37

22M-43-21560

SPRING

38

04050-12015

PIN, COTTER

39

01643-10823

WASHER

40

22M-43-21170

SWITCH, ASSY.

41

37A-09-1W059

SCREW

42

21D-06-12880

PLUG
