Запчасти Komatsu PC35MR-2 РЫЧАГ УПРАВЛ-Я ХОДОМ (ДЛЯ КАБИНЫ) СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА

1

20Y-43-21151

COVER

2

20Y-43-21260

COLLAR

3

01010-D1025

BOLT

4

203-54-56970

WASHER

5

22M-43-21391

LEVER, L.H.

6

22M-43-21381

LEVER, R.H.

7

01252-71025

BOLT

8

01643-11032

WASHER

9

20Y-43-21231

KNOB, L.H.

10

20Y-43-21241

KNOB, R.H.

11

37A-09-1W030

SCREW

12

22M-13-11590

DAMPER

13

04205-10830

PIN

14

04050-12015

PIN, COTTER

15

01010-80830

BOLT

16

01643-10823

WASHER

17

702-16-01950

PILOT VALVE

18

01010-D1025

BOLT

19

01643-11032

WASHER

20

11Y-62-R2140

UNION

21

890001115

O-RING

22

02896-11008

O-RING

23

21W-62-R3970

ELBOW

24

02896-11008

O-RING

25

890001115

O-RING

26

20T-910-R660

UNION

27

890001115

O-RING

28

37D-09-71531

ELBOW

29

02896-11008

O-RING

30

21D-09-69960

O-RING

31

22M-43-22111

PLATE

32

20Y-43-21260

COLLAR

33

203-43-51620

SPRING

34

20Y-43-21140

COVER

35

01016-51030

BOLT

36

01643-11032

WASHER

37

22M-62-23160

HOSE

37

21U-62-34750

BAND

37

21U-62-34770

BAND

38

22M-62-23170

HOSE

38

21U-62-34730

BAND

38

21U-62-34760

BAND

39

08034-20414

CLAMP

40

01643-11032

WASHER

41

01640-20408

WASHER

42

22M-62-R3330

UNION
