Запчасти Komatsu PC35MR-2 ГИДРОЛИНИЯ (ГИДРОЛИНИЯ СТРЕЛЫ) (КЛАПАН БЕЗОПАСНОСТИ) (С ДАТЧИКОМS) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

1

22L-09-R2T20

VALVE, ASSY.

2

845250548

KIT, GASKET

3

22L-931-2150

UNION

4

37D-09-66105

UNION

5

37B-09-15617

O-RING

6

02896-11009

O-RING

7

226-09-12690

UNION

8

21D-09-69960

O-RING

9

02896-11008

O-RING

10

226-09-12790

ELBOW

11

21D-09-69960

O-RING

12

02896-11008

O-RING

13

22L-09-R1680

UNION

14

21D-09-69960

O-RING

15

37B-09-88002

O-RING

16

37D-09-7R870

TEE

17

02896-11008

O-RING

18

37D-09-7F750

TEE

19

02896-11008

O-RING

20

22L-60-23140

CLAMP

21

22L-60-23190

HOSE

22

22L-60-23180

HOSE

23

22L-60-23160

HOSE

24

22L-09-R1670

PROTECTION

25

08034-20823

CLAMP

26

22L-60-23130

SUPPORT

27

01016-50825

BOLT

28

20S-60-13120

VALVE

29

01252-70540

BOLT

30

01640-20508

WASHER

31

21D-09-23140

NUT, STOP

32

226-09-12790

ELBOW

33

21D-09-69960

O-RING

34

02896-11008

O-RING

35

22F-60-23110

HOSE

36

22L-09-R1690

WIRING HARNESS

37

22L-09-R1970

WIRING HARNESS

38

22L-09-R1980

WIRING HARNESS

39

08034-20519

CLAMP

40

22L-09-R2T40

PUSH-BUTTON

41

22L-09-R2T80

GLASS

42

22L-09-R7370

PIPE

43

02896-11009

O-RING

44

08034-20834

CLAMP

45

22L-09-R1Z90

PROTECTION

46

22L-09-R2U70

BRACKET

47

22L-09-R2U50

FASTENING PLATE

48

22L-09-R2U60

FASTENING PLATE

49

01580-10806

NUT, STOP

50

21D-09-24160

NUT

51

01643-10823

WASHER

52

01010-80845

BOLT

53

01643-10823

WASHER
