Запчасти Komatsu PC35MR-2 ГИДРАВЛ МАСЛ. БАК РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

1

22L-60-R2113

TANK

2

22L-09-R1360

PLUG

3

07002-02434

O-RING

4

21U-60-32120

FILTER

5

07000-12085

O-RING

6

01010-81025

BOLT

7

01643-11032

WASHER

8

209-60-R1180

UNION

9

22L-60-22171

PLATE

10

01010-81020

BOLT

11

01643-11032

WASHER

12

07270-00890

PIPE

13

37A-09-5M606

CLAMP

14

22L-60-R2161

PIPE

15

22E-60-11120

ELBOW

16

22L-60-22152

SHEET

17

02896-11009

O-RING

18

22E-98-11230

MARK PLATE, SAFETY, HYDRAULIC OIL LEVEL

19

22L-60-22212

FLANGE

20

22L-60-22120

ELEMENT

21

22L-60-R2130

VALVE, ASSY.

22

22L-60-22140

SPRING

23

07000-12120

O-RING

24

01010-81025

BOLT

25

01643-11032

WASHER

26

22L-60-R2222

CASE

27

07000-12125

O-RING

28

8A30601110

BLOCK

29

8A30501120

CYCLONE

30

01252-70625

BOLT

31

01643-10623

SPRING WASHER

32

07043-70211

PLUG

33

07000-12080

O-RING

34

01010-80620

BOLT

35

01643-10623

SPRING WASHER

36

3F0565073

UNION

37

855670031

O-RING

38

22L-09-R1150

UNION

39

07002-12434

O-RING

40

02896-11015

O-RING

41

22L-60-22180

DAMPER

42

22L-60-22190

SHEET

43

01016-51030

BOLT

44

01643-11032

WASHER

45

02896-11008

O-RING
