Запчасти Komatsu PC35MR-2 ОСНОВНАЯ РАМА(№-9) ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

22F-46-21116

FRAME,REVOLVING

1

22F-46-21115

FRAME,REVOLVING

1

22F-46-21114

FRAME,REVOLVING

1

22F-46-21113

FRAME,REVOLVING

2

22F-46-21320

BUSHING

3

07145-00100

SEAL,DUST

4

07020-00000

FITTING,GREASE

5

07020-00675

FITTING,GREASE

6

22L-46-21152

BRACKET

7

01010-81020

BOLT

8

01643-31032

WASHER

9

22L-46-21161

COVER

10

01010-81020

BOLT

11

01643-31032

WASHER

12

22L-46-21181

COVER

13

01435-00812

BOLT

14

22L-46-21371

BRACKET

15

01010-80816

BOLT

16

01643-30823

WASHER

17

22L-46-21381

BRACKET

17

22L-46-21380

BRACKET

18

01010-81025

BOLT

19

01643-31032

WASHER

20

22L-46-21421

SHEET

20

22L-46-21420

SHEET

21

21U-54-31250

WASHER

22

01010-80610

BOLT

23

20T-62-71790

GROMMET

24

22L-46-21173

SHEET

25

22L-46-21191

SHEET

26

22L-46-21311

SHEET

27

22L-46-21341

SHEET

28

22L-46-21351

SHEET

29

22L-46-21361

SHEET

30

22L-46-21391

SHEET

31

22L-46-21410

SHEET

32

22L-46-21280

SHEET
