Запчасти Komatsu PC35MR-2 ОСНОВН. КЛАПАН (СОЕДИНИТЕЛЬН. ЧАСТИ) (/) ( НАВЕСН.ОБОРУД) (КРОМЕ ЯПОН.) ГИДРАВЛИКА

1

723-19-12604

CONTROL VALVE,(SEE FIG.Y1662-21A0)

1

723-19-12603

CONTROL VALVE,(SEE FIG.Y1662-21A0)

1

723-19-12602

CONTROL VALVE,(SEE FIG.Y1662-21A0)

1

723-19-12601

CONTROL VALVE,(SEE FIG.Y1662-21A0)

1

723-19-12600

CONTROL VALVE,(SEE FIG.Y1662-21A0)

2

22L-60-21221

BRACKET

3

01010-81030

BOLT

4

01643-31032

WASHER

5

22F-60-21223

BRACKET

5

22F-60-21222

BRACKET

6

01010-80820

BOLT

7

01643-30823

WASHER

8

02782-10420

ELBOW

9

02896-11012

O-RING

10

07002-11823

O-RING

11

02782-1052A

ELBOW

12

02896-11015

O-RING

13

07002-12434

O-RING

14

21W-62-42420

UNION

15

02896-11009

O-RING

16

07002-11823

O-RING

17

02782-10210

ELBOW

18

02896-11008

O-RING

19

07002-11423

O-RING

20

22F-62-22161

HOSE

21

22F-62-22510

ELBOW

22

02896-11012

O-RING

23

07002-11823

O-RING

24

02782-10210

ELBOW

25

02896-11008

O-RING

26

07002-11423

O-RING

27

02782-10314

ELBOW

28

02896-11009

O-RING

29

07002-11823

O-RING

30

02782-10212

ELBOW

31

02896-11008

O-RING

32

07002-11423

O-RING

33

22F-62-22151

HOSE

34

02781-0021D

UNION

35

02896-11008

O-RING

36

07002-11423

O-RING

37

22L-62-22862

HOSE
