Запчасти Komatsu PC35MR-2 ГИДР. БАК. ГИДРАВЛИКА

1

22L-60-22113

TANK

2

07044-12412

PLUG

3

07002-12434

O-RING

4

21U-60-32120

STRAINER

5

07000-12085

O-RING

6

01010-81030

BOLT

7

01643-31032

WASHER

8

209-60-51180

CAP

9

22L-60-22171

PLATE

10

01010-81020

BOLT

11

01643-31032

WASHER

12

07270-00890

TUBE

12

07270-00893

TUBE

13

07285-00095

CLIP

14

22L-60-22161

TUBE

|$23

203-60-31100

ELBOW ASS'Y

15

ELBOW

16

NUT

17

203-60-31250

SLEEVE

18

203-00-31120

PLATE, INSTRUCTION

19

22L-60-22212

FLANGE

20

22L-60-22120

ELEMENT

21

22L-60-22130

VALVE ASS'Y

22

22L-60-22140

SPRING

23

07000-12120

O-RING

24

01010-81025

BOLT

25

01643-31032

WASHER

26

22L-60-22222

CASE

26

22L-60-22221

CASE

27

07000-12125

O-RING

|$42

8A30-60-1101

CYCLONE ASS'Y

|$43

8A30-60-1100

CYCLONE ASS'Y

28

BLOCK

28

BLOCK

29

CYCLONE

30

01252-70625

BOLT

31

01643-30623

WASHER

32

07043-70211

PLUG

33

07000-12080

O-RING

34

01010-80620

BOLT

35

01643-30623

WASHER

36

20M-62-82271

NIPPLE

37

07002-12434

O-RING

38

02781-00522

UNION

39

07002-12434

O-RING

40

22L-60-22152

SHEET

41

22L-60-22180

CUSHION

42

22L-60-22190

SHEET

43

01010-81030

BOLT

44

01643-31032

WASHER

45

02896-11008

O-RING

46

02896-11009

O-RING

47

02896-11015

O-RING
