Запчасти Komatsu PC35MR-2-A ОСНОВН. КЛАПАН (9-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-19-12300

CONTROL VALVE

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-22A0.

|1

VALVE SUB ASS'Y

1

SPOOL

2

PLUG

3

ORIFICE

4

07002-10823

O-RING

5

RING

6

723-11-14330

SEAT

7

723-11-14150

SPRING

8

723-11-13490

CASE,SPRING

9

702-21-54260

O-RING

10

702-21-55520

O-RING

11

01252-60625

BOLT

12

723-11-18190

PLUG

13

07002-11023

O-RING

14

723-11-14310

ORIFICE

15

07000-11010

O-RING

16

RING

17

SCREW

18

PLUG

19

07000-12100

O-RING

20

723-11-19130

O-RING

21

07000-11006

O-RING

22

702-21-54260

O-RING

23

01252-60635

BOLT

24

708-8H-11530

PLUG

25

07002-11423

O-RING

26

PLUG

27

07000-11006

O-RING

28

07001-01006

RING
