Запчасти Komatsu PC35MR-2-A МОТОР ХОДА (ПОНИЖАЮЩ. ПЕРЕДАЧА) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22L-60-21101

MOTOR ASS'Y,TRAVEL

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0¤ 02A0 AND 03A0.

|1

FUGHB-3-8243

BODY SUB ASS'Y

1

BODY

2

FU130BA-16

BEARING

3

RING,SNAP

4

FUJS1480F

FLOATING SEAL ASS'Y

5

FUFRP-614-25-X

RING,SNAP

6

FUFZD8718-1-06

GEAR

7

FUFZD8388-1-20

NEEDLE

8

FUFZD8718-1-10

RING

9

FUFZD8388-1-40

WASHER,THRUST

10

FUFZD8388-1-41

WASHER,THRUST

11

04064-02815

RING,SNAP

|12

FUGHC-29028718

CARRIER ASS'Y

12

CARRIER

13

GEAR

14

GEAR

15

PIN B2

16

NEEDLE

17

WASHER,THRUST

18

04064-03015

RING,SNAP

19

04064-02512

RING,SNAP

20

21U-60-16260

PIN,SPRING

21

FUFZD8388-1-15

COLLAR,THRUST

22

FUFZD8718-1-09

GEAR

23

FUFZD8603-1-16

RING,SLIDE

24

FUFZD8388-1-02

COVER

25

FUFRP-1015-13

RING,SNAP

|26

FUGHS-1-8878

SEAL KIT

26

20N-60-72130

O-RING

27

07000-12014

O-RING

28

07000-11008

O-RING

29

FUFZD8144-1-34

PLUG

30

FUGPF-1/8

PLUG

31

FUNV65

NAME PLATE
