Запчасти Komatsu PC35MR-1 РАБОЧ. УПРАВЛ-Е (КОНТРОЛЬ ХОДА /) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

04210-20832

YOKE

2

01580-10806

NUT

3

04220-20832

YOKE,L.H. THREAD

4

01508-40805

NUT,L.H. THREAD

5

04205-10822

PIN

|5

04205-30822

PIN

6

04050-12015

PIN,COTTER

|6

04052-10833

PIN,SNAP

7

04248-30821

ROD

8

20N-43-41290

BEARING

9

01010-80816

BOLT

10

01643-30823

WASHER

11

22F-43-17320

LEVER

|11

22L-43-11250

LEVER

|11

06600-00805

BUSHING

12

22F-43-11140

PIN

13

01643-32060

WASHER

14

22F-43-11121

LEVER

|14

06600-00805

BUSHING

15

06124-02020

BEARING

16

22F-43-11131

SHAFT

17

22L-43-11250

LEVER

|17

06600-00805

BUSHING

18

22F-43-11140

PIN

18A

22L-43-18310

ROD

19

20M-43-48290

YOKE

|19

21U-43-31280

SHAFT

19A

01508-40805

NUT,L.H. THREAD

20

04205-10520

PIN

|20

04205-10518

PIN

21

04050-11210

PIN,COTTER

|21

04052-10530

PIN,SNAP

21A

20M-43-48271

YOKE

21B

01580-10806

NUT

22

04205-10820

PIN

|22

04205-30820

PIN

23

04050-12015

PIN,COTTER

|23

04052-10833

PIN,SNAP

24

22F-43-11170

DAMPER

25

01010-80840

BOLT

26

01643-30823

WASHER

27

01580-10806

NUT
