Запчасти Komatsu PC350NLC-8 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) (№K-) C СИСТЕМА ОХЛАЖДЕНИЯ

1

207-03-75121

RADIATOR ASSEMBLY

|1

207-03-75120

RADIATOR ASSEMBLY

2

20Y-03-22110

CAP

3

205-03-71230

HOSE

4

20Y-03-11330

CLIP

5

205-03-62660

PLUG

6

07000-11007

O-RING

7

208-03-71730

SEAL

8

208-03-71810

SEAL

9

208-03-71840

SEAL

10

14X-03-51640

SPACER

11

207-03-76450

BRACKET

12

01010-81235

BOLT

13

01643-31232

WASHER

14

14X-03-51621

CUSHION

15

14X-03-51770

PLATE

16

01010-81045

BOLT

17

207-03-75171

FRAME

18

207-03-75181

FRAME

19

207-03-76341

FRAME

19

207-03-76340

FRAME

20

01010-81225

BOLT

21

01643-31232

WASHER

22

207-03-76350

FRAME

23

01010-81030

BOLT

24

01643-31032

WASHER

25

01010-81020

BOLT

26

01643-31032

WASHER

27

22B-03-12590

CUSHION

28

208-03-71380

CUSHION

29

208-03-71480

SEAL

30

208-03-71490

SEAL

31

208-03-71780

SEAL

32

207-03-76410

SEAL

33

208-03-71821

SEAL

34

208-03-71830

SEAL

35

207-03-76320

OIL COOLER

36

207-03-76330

FRAME

37

207-03-76380

SEAL

38

207-03-76390

SEAL

39

207-03-76420

SEAL

40

208-03-71131

OIL COOLER

41

208-03-71690

SEAL

42

208-03-71850

SEAL

43

208-03-71860

SEAL

44

208-03-71870

SEAL

45

208-03-71890

SEAL

46

01010-81020

BOLT

47

01643-31032

WASHER

48

01010-81240

BOLT

49

01643-31232

WASHER

50

07000-13045

O-RING

51

01010-81030

BOLT

52

01643-31032

WASHER

53

01010-81225

BOLT

54

01643-31232

WASHER
