Запчасти Komatsu PC350LL-7E0 T-A LOG ПОГРУЗ. ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0L140

CYLINDER ASSEMBLY

1

707-13-16220

CYLINDER

2

707-76-90610

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

07043-00108

PLUG

6

707-58-11730

ROD

7

707-76-11130

BUSHING

8

07145-00110

SEAL, DUST

9

707-71-31670

COLLAR

10

707-35-91640

RING, BACK-UP

11

07000-15150

O-RING

12

707-71-61140

PLUNGER

13

707-27-16580

HEAD

14

198-63-94170

SEAL, DUST

15

07179-13126

RING, SNAP

16

707-52-90850

BUSHING

17

707-75-11040

RING, SNAP

18

707-51-11030

PACKING, ROD

19

707-51-11640

RING, BUFFER

20

707-35-91640

RING, BACK-UP

21

07000-15150

O-RING

22

01010-82085

BOLT

23

707-88-75310

WASHER

24

707-36-16580

PISTON

25

01310-01216

SCREW

26

707-44-16180

RING, PISTON

27

707-39-16120

RING, WEAR

28

707-44-16910

RING

29

07001-05100

RING, BACK-UP

30

07000-15100

O-RING

31

707-86-13770

TUBE, L.H.

|$32

707-86-13790

TUBE, R.H.

32

707-86-13780

TUBE, L.H.

|$34

707-86-13810

TUBE, R.H.

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07000-13035

O-RING

36

707-88-50130

BRACKET, L.H.

|$39

707-88-50140

BRACKET, R.H.

37

707-88-50150

BAND, L.H.

|$41

707-88-50160

BAND, R.H.

38

07372-21240

BOLT

39

01643-51032

WASHER

40

07283-33442

U-BOLT

41

01643-31032

WASHER

42

01597-01009

NUT

43

01010-81030

BOLT

44

01643-31032

WASHER

|$49

707-99-67870

SERVICE KIT, BOOM CYLINDER
