Запчасти Komatsu PC350LC ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (№K7-)

|1

707-E1-X0530

CYLINDER ASS'Y

1

707-13-14450

CYLINDER

2

707-76-80330

BUSHING

3

07145-00080

SEAL (KIT)

4

07020-00000

FITTING

5

721-58-10200

ROD

6

707-76-80330

BUSHING

7

07145-00080

SEAL (KIT)

8

07020-00000

FITTING

9

707-27-14150

HEAD

10

707-56-10740

SEAL (KIT)

11

07179-13114

RING

12

707-52-90780

BUSHING

13

707-51-10030

PACKING (KIT)

14

707-51-10650

RING (KIT)

15

07000-05135

RING (KIT)

16

07000-15135

O-RING (KIT)

17

01011-81820

BOLT

18

707-41-11840

WASHER

19

707-36-14410

PISTON

20

01310-01220

SCREW

21

707-44-14150

RING (KIT)

22

707-39-14820

RING (KIT)

23

707-44-14910

RING

24

07001-05090

RING (KIT)

25

07000-15090

O-RING (KIT)

26

707-63-K1590

TUBE

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07000-13035

O-RING (KIT)

30

707-88-87180

BRACKET

31

707-88-87170

BAND

32

07372-21240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-51232

WASHER

|$39

707-99-59040

SERVICE KIT
