Запчасти Komatsu PC350LC 1-Я СТРЕЛА В СБОРЕ
№
Артикул
Название
Примечание
Количество
1
207-70-KG111
BOOM
|1
207-70-KG110
BOOM
2
207-62-KG190
TUBE
3
207-62-KG210
TUBE
4
07371-30500
FLANGE
5
01010-80830
BOLT
6
01643-50823
WASHER
7
207-62-KH670
TUBE
|7
207-62-KG180
TUBE
8
21P-62-K3270
BAND (WHITE)
9
07371-31049
FLANGE
10
07372-21035
BOLT
11
01643-51032
WASHER
12
207-62-KH660
TUBE
|12
207-62-KG170
TUBE
13
21P-62-K3240
BAND (RED)
14
207-62-KG160
TUBE
15
21P-62-K3260
BAND (BLUE)
16
207-62-KH650
TUBE
|16
207-62-KG150
TUBE
17
21P-62-K3280
BAND (BLACK)
18
208-62-85980
TUBE
19
07000-13029
O-RING
20
07000-13032
O-RING
21
208-62-86130
VALVE
22
207-62-83980
TUBE
23
01010-81060
BOLT
24
01643-31032
WASHER
25
07000-13035
O-RING
26
207-64-82430
TUBE
27
07000-13029
O-RING
28
07378-10500
HEAD
29
07000-13022
O-RING
30
07371-30500
FLANGE
31
01010-80830
BOLT
32
01643-50823
WASHER
33
207-62-KG110
TUBE
34
21P-62-K3290
BAND (GREEN)
35
207-62-KG120
TUBE
36
207-62-KH810
BAND (GREY)
37
207-62-KG130
TUBE
38
21P-62-K3310
BAND (BROWN)
39
207-62-KG140
TUBE
40
21P-62-K3250
BAND (YELLOW)
41
208-62-85940
TUBE
42
07000-13022
O-RING
43
07000-13024
O-RING
44
208-62-86140
VALVE
45
207-64-82320
TUBE
46
07000-13024
O-RING
47
07378-11410
HEAD
48
07000-13048
O-RING
49
07371-51470
FLANGE
50
07372-21455
BOLT
51
01643-31445
WASHER
52
07378-11000
HEAD
53
07000-13032
O-RING
54
07371-31049
FLANGE
55
07372-21035
BOLT
56
01643-51032
WASHER
57
207-62-KG260
TUBE
58
07371-30500
FLANGE
59
01010-80830
BOLT
60
01643-50823
WASHER
61
207-62-KG250
CLAMP
62
01010-81245
BOLT
63
01643-31232
WASHER
64
207-62-KG430
CLAMP
65
01010-81250
BOLT
66
01643-31232
WASHER
67
207-62-88880
CLAMP
68
208-62-85780
CUSHION
69
209-62-58520
SEAT
70
205-62-54622
SEAT
71
01010-81245
BOLT
72
01643-31232
WASHER
73
01010-81250
BOLT
74
01643-31232
WASHER
75
207-62-88690
CLAMP
76
208-62-85780
CUSHION
77
207-62-84223
CLAMP
78
01010-81245
BOLT
79
01643-31232
WASHER
80
207-62-31330
CLAMP
81
01010-81235
BOLT
82
01643-31232
WASHER
83
207-62-54760
CLAMP
84
01010-81235
BOLT
85
01643-31232
WASHER
86
207-970-7162
BRACKET
87
01010-81245
BOLT
88
01643-31232
WASHER
89
207-970-7310
CLAMP
90
01010-81235
BOLT
91
01643-21232
WASHER
92
207-62-31330
CLAMP
93
01010-81245
BOLT
94
01643-31232
WASHER
95
07378-11210
HEAD
96
07000-13038
O-RING
97
07371-51260
FLANGE
98
07372-21245
BOLT
99
01643-31445
WASHER
100
207-62-31330
CLAMP
101
01010-81235
BOLT
102
01643-31232
WASHER
103
207-62-KB730
CONNECTOR (SEE PAGE 360450)
104
02781-00516
UNION
105
07002-12034
O-RING
106
02896-11015
O-RING
107
02781-00422
UNION
|107
02781-00422
UNION
108
07002-12034
O-RING
|108
07002-12034
O-RING
109
02896-11012
O-RING
|109
02896-11012
O-RING
110
207-62-KF350
NIPPLE
111
07002-12034
O-RING
112
02896-11012
O-RING
113
207-62-KB490
JOINT
114
207-62-KB471
SEAL
115
01010-81280
BOLT
116
01643-31232
WASHER
117
207-70-KC912
PLATE
|117
207-70-KC911
PLATE
118
01010-80850
BOLT
119
01643-31232
WASHER
120
120-54-42430
SPACER
121
207-62-KE380
SOCKET (QUICK COUPLER)
122
207-62-KE760
O-RING
123
207-62-KE430
CAP
124
207-62-KE390
PLUG (QUICK COUPLER)
125
207-62-KE760
O-RING
126
207-62-KE440
CAP
127
207-62-KE370
PLUG (QUICK COUPLER)
128
207-62-KE760
O-RING
129
207-62-KE420
CAP
130
207-62-KE410
SOCKET (QUICK COUPLER)
131
207-62-KE760
O-RING
132
207-62-KE450
CAP
133
02756-00506
HOSE
134
02757-00506
HOSE
135
02753-00422
HOSE
136
02753-00622
HOSE
137
07095-00420
CUSHION
138
07094-10620
CLAMP
139
07094-30417
CLAMP
140
01010-81295
BOLT
141
01643-31232
WASHER
142
01010-81290
BOLT
143
01643-31232
WASHER
144
KV-B240-8080
BLOCK
145
02781-00422
UNION
|145
02781-00422
UNION
146
07002-12034
O-RING
|146
07002-12034
O-RING
147
02896-11012
O-RING
|147
02896-11012
O-RING
148
207-62-KF350
NIPPLE
149
07002-12034
O-RING
150
02896-61018
O-RING
151
02756-00508
HOSE
152
207-62-KH250
COUPLER
|153
207-62-KH950
COUPLER
153
207-62-KH960
CARTRIDGE ASSEMBLY
154
207-62-KH970
NUT
155
207-62-KH980
RING
156
207-62-KH940
PIN
157
207-62-KH610
CAP, DUST
158
207-62-KJ780
O-RING
159
207-62-KE760
O-RING
160
207-70-KJ980
BRACKET
161
01010-81225
BOLT
162
01643-31232
WASHER
163
07095-10627
CUSHION
164
01011-81200
BOLT
165
01643-31232
WASHER
Выбрано товаров: 177
